P/N: FN133PGRGUL
Structure: G+G
TP VA (mm): 294.17*165.78
Outline (mm): 341.17*212.78
Sensor OD(mm): 309.34*188.37
OP(℃): -20-70
ST(℃): -30-80
Interface: USB
CTP IC: Microchip
| Structure | Materials | Remark |
| Cover Glass | Chemical strengthened glass with AG/AF | Thickness: 3.0mm±0.05mm |
| Optical clear adhesive | OCR | Thickness: 0.175mm±0.05mm |
| ITO Glass | ITO Glass | Double side ITO glass; Thickness: 0.7mm±0.05mm |
| Item | Description | Unit |
| Touch Module Size | 13.3 | inch |
| Outer Dimension | 341.17*212.78 | mm |
| View Area | 294.17*165.78 | mm |
| Sensor Area | 309.34*188.37 | mm |
| Cover Thickness | 3.0 | mm |
| Number of Touch | 10 | |
| Input Type | USB | |
| Control Type | Microchip |
